Commercial Aerospace Launchpad GSE

Design | Build | Integration


INSYSMA and it's industry partners have a specialized knowledge and interest in NASA GSE design.  Specifically, Ground-Based Pressure Vessel & Pressurized Systems & Components rated to up to 10,000 PSI.

Specifications:

>> NASA-STD-8719.17

     Requirements for Ground-Based Pressure Vessels and Pressurized Systems (PVS)

>> AIR FORCE SPACE COMMAND MANUAL 91-710 VOLUME 3

     Range Safety User Requirements Manual - Launch Vehicles, Payloads, and Ground Support Systems

>> ASME Boiler Pressure Vessel Code Section VIII Division 1, 2 & 3

     Rules  for Construction of Pressure Vessels

We can design, build and qualify any type of pressure-flow translated mechanical device such as:

  • Application specific Large Hydraulic Cylinders - ASME BPVC Section VIII compliant or certified
  • Application specific Rotary Hydraulic Actuators, 3000 PSI & 4mm lb-ft - ASME BPVC Section VII
  • GN2 piston type accumulators - ASME BPVC Section VIII compliant or certified
  • Hydraulic Power System (HPS or HPU) skids with large displacement pumps and heavy duty motors
  • Custom valve and header pipe block manifolds
  • Piping with full penetration (CJM) welds to ASME B31.1
  • Weld-less piping systems  - ASME B31.1, MIL-S-901D, NAVSEA, ABS approved
  • Custom Closed & Open Loop Hydraulic  & Controls Circuitry
  • GN2 or Instrument Quality Air Systems for Purge, Blanketing and Stored Energy

To support our clients vis-a-vis NASA Range Safety, increase Mission Assurance, and limit the amount of request waivers, we offer in-house services:

  • ATEX / IEC FM / UL / CSA Explosive Environment Compliance
  • ASME "U" Stamp Certification
  • Quality Provision Compliance
  • Failure Modes & Effects Analysis with Critical Load Path Diagram
  • Range Safety Manual Compliance

To ensure proper integration and Interfacing, we can offer:

  • Installation Support with mobilization of Heavy Machinery, Field Piping, Field Conduit, Wiring Test & Check-out
  • Modifications to existing HPU and Controls
  • Software Integration and Post-Installation Axis Control Tuning
  • Local Machine Control & Fieldbus Communication Handshake Interfacing
  • Dynamic Modeling of Wind Load Cases
  • Factory & Field Hydrostatic Testing with Procedures, Manuals & Reports

Please give us a call to discuss your project or just looking for ideas:  (888) 409-7230
